--- Equal power transmission
--- High loads,low elongation and long service life
--- Excellent operational safety
--- Temperature range from -55℃ to 70℃
--- Static conductive to ISO1813
--- Oil,heat,Ozone and abrasion resistant
Product Details
Place of Origin: Zhejiang, China
Brand Name: SINOCONVE
Certification: ISO 9001
Payment & Shipping Terms
Minimum Order Quantity: 50 pieces
Price: $1.86/pieces 50-99 pieces
Packaging Details: Fan v belts are packed in carton
carton size: 65x37x26cm
Warranty: |
None |
Applicable Industries: |
Retail, Energy & Mining |
Standard Or Nonstandard: |
Standard |
Type: |
V-BELT, 3L,4L,5L |
Material: |
Rubber |
Product Name: |
Lawn Mower Belt |
Temperature Range: |
-55℃ To 70℃ |
Outside Fabric:: |
Polyester Cotton Canvas |
Reinforcement: |
Polyester Cord |
Top Rubber: |
NR,SBR |
Size: |
A50,A56,B98,C112, |
Application: |
Wedge V Belt |
Key Words: |
V Belt Price |
Warranty: |
None |
Applicable Industries: |
Retail, Energy & Mining |
Standard Or Nonstandard: |
Standard |
Type: |
V-BELT, 3L,4L,5L |
Material: |
Rubber |
Product Name: |
Lawn Mower Belt |
Temperature Range: |
-55℃ To 70℃ |
Outside Fabric:: |
Polyester Cotton Canvas |
Reinforcement: |
Polyester Cord |
Top Rubber: |
NR,SBR |
Size: |
A50,A56,B98,C112, |
Application: |
Wedge V Belt |
Key Words: |
V Belt Price |
--- Equal power transmission
--- High loads,low elongation and long service life
--- Excellent operational safety
--- Temperature range from -55℃ to 70℃
--- Static conductive to ISO1813
--- Oil,heat,Ozone and abrasion resistant
Top rubber: NR,SBR
Reinforcement: Polyester cord
Buffer rubber: NR,SBR
Bottom rubber: NR,SBR
Outside fabric: Polyester cotton canvas
--
Mower power transmissionClassical V belt:
Type | Top width | Pitch width | Height | Length range | Angle |
mm | mm | mm | mm | ||
Z/M/FM/O | 10 | 8.5 | 6 | 280---2480 | 40° |
A | 13 | 11 | 8 | 330---8000 | 40° |
B | 17 | 14 | 11 | 457---17000 | 40° |
C | 22 | 19 | 14 | 700---17000 | 40° |
D | 32 | 27 | 19 | 1100---17000 | 40° |
E | 38 | 32 | 23 | 3300---17000 | 40° |
Narrow V belt:
Type | Top width | Pitch width | Height | Length range | Angle |
mm | mm | mm | mm | ||
3V | 9.5 | / | 8 | 375--3353 | 40° |
5V | 16 | / | 13.5 | 795---17000 | 40° |
8V | 25.5 | / | 23 | 2500---17000 | 40° |
SPZ | 10 | 8 | 8 | 375---3353 | 40° |
SPA | 13 | 11 | 10 | 475---7200 | 40° |
SPB | 17 | 14 | 14 | 750---17000 | 40° |
SPC | 22 | 19 | 18 | 1350---17000 | 40° |
Other special types:
Type | Top width | Pitch width | Height | Angle |
mm | mm | mm | ||
3L | 9.8 | / | 5.6 | 40° |
4L | 12.7 | / | 8 | 40° |
5L | 16.8 | / | 10.5 | 40° |
8.5*8 | 10.5 | 8.5 | 8 | 40° |
Banded Jointed Rubber V belt:
Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
1) 2--3 days for sample
2) 20--30 days for mass production. If urgent,we have green channel.
Low MOQ, 1pc for sample checking is available
Yes. Please inform us your logo or design before mass production
We are one of the top suppliers of International famous Belt company over years. Excellent quality is well accepted.
Please contact us for more details.
